The height adjustment of the laser head of the pipe laser cutting machine is a key step that directly affects the accuracy and quality of cutting. The following are detailed methods and precautions for adFiber Multifunctional Laser Cutting Machines justing the height of the laser head of the pipe laser cutting machine.

一、 Preparation work
Before making adjustments, preparations must be made to ensure safety and effectiveness. Confirm the thickness of the sheet to be cut and select the corresponding focusing lens. In addition, it is necessary to wear safety goggles and other tools to prevent the laser of the pipe laser cutting machine from causing eye damage.
二、 Method for adjusting the height of laser head
To adjust the height of the laser head, the following steps need to be followed:
1. Confirm the thickness of the cutting plate and select a suitable focusing lens.
Before adjusting the laser head of the pipe laser cutting machine, it is necessary to wear safety protective tools such as protective goggles.
3. Start the laser, place the sheet flat on the laser worktable, and press the "Preview/Swap" button to observe the movement trajectory of the laser and find the point where the laser contacts the sheet.
4. Control the height of the workbench by adjusting the lifting handwheel of the workbench, so that it differs from the height of the laser head by 3-5 millimeters.
5. Adjust the 26K lens on the laser head and adjust the height according to the thickness of the board. When the thickness of the board changes significantly, it needs to be readjusted.
6. Use a visual ruler to adjust the position of the laser head, that is, adjust the visual ruler to the laser focal point.
三、 Precautions
Before adjusting the laser head, there are several points to note:
1.Before starting the laser, be sure to wear protective goggles and other safety equipment.
2. Choose a suitable focusing lens to adapt to the thickness of the current sheet, otherwise it may affect the cutting effect of the pipe laser cutting machine.
3. The laser head should not come into direct contact with the workpiece, and its height should generally be maintained at around 3-5 millimeters.
4. When adjusting the laser head, it should be moved slowly to avoid sudden changes that may cause damage to the equipment.
四、 Common problem solutions
Here are some solutions to common problems:
1.If the focus of the pipe laser cutting machine is too high or too low during cutting, it can be solved by adjusting the height of the worktable or adjusting the 26K lens on the laser head.
2. If the incision does not lift or lifts incompletely during cutting, it may be due to inaccurate laser focus. Need to readjust the laser head to solve the problem.

3.If the surface of the cut material is not smooth, it may be due to the contact distance between the laser head and the workpiece being too close or too far. Need to readjust the height of the laser head to solve the problem.

Through the introduction in this article, I believe everyone has understood the debugging method, precautions, and common problem solutions for the laser head of the pipe laser cutting machine. Special attention should be paid to safety when adjusting the laser head, and the operation should be carried out slowly to avoid damage to the equipment.
